- Published on
Binary data and universal JavaScript
- Authors
- Name
- Guillaume C. Marty
- Engineering manager, available for hire
Power skill coach at Skiller Whale
With Node.js 20, it has never been that easy to write code to create or process binary data that can run in both the browser and Node.js. No more polyfills needed! Let’s take a look at what’s new.
ArrayBuffer support in Node.js
Traditionally, the way to deal with binary files in Node.js was to use the proprietary Buffer
API. Thankfully, the standardised BufferArray
API landed in Node.js 20 (the current LTS release). This unlocks cross-platform code compatible with both Node.js and the browser.
If you’re used to working with Buffer
in Node.js, here is a quick introduction to ArrayBuffer
.
What’s an ArrayBuffer and how to work with it?
An ArrayBuffer
is a very simple data structure. The name is confusing, you can’t use any of the array methods. In fact, there is very little you can do with ArrayBuffer
alone:
const length = 8
const arrayBuffer = new ArrayBuffer(length)
arrayBuffer.byteLength // 8
const headerBuffer = arrayBuffer.slice(0, 4)
headerBuffer.byteLength // 4
Unlike a Buffer
in Node.js, an ArrayBuffer
can be resized, if defined as so at creation time:
const arrayBuffer = new ArrayBuffer(8, { maxByteLength: 16 })
arrayBuffer.byteLength // 8
arrayBuffer.resize(12)
arrayBuffer.byteLength // 12
This is useful if you’re writing data on the go (from a stream for example) and don’t know in advance how big your ArrayBuffer
will be.
Buffer vs. DataView
As we saw above, an ArrayBuffer
on its own is pretty useless. It becomes powerful when paired with a DataView
to read and write to it:
const arrayBuffer = new ArrayBuffer(8)
const view = new DataView(arrayBuffer)
view.setUint8(0, 64)
view.setUint16(1, 1024)
There are a few differences between Node’s Buffer
and DataView
however. The methods to read data in both cases are similar but different, which can cause confusion. Buffer
uses the verbs read
and write
(e.g. buf.readUInt8(0)
), while in DataView
the methods start with get
and set
(e.g. view.getUint8(0)
). Also the case of the type you want to read is different (UInt vs. Uint).
The endianness is treated differently too. In Node.js, you have dedicated methods (buf.readUInt16BE(0)
for big endian and buf.readUInt16LE(0)
otherwise). In DataView
, big endian is the default. You’ll pass an additional parameter for little endian (e.g. view.getInt16(0, true)
).
The good news is you can forget about the Buffer
API now. Using ArrayBuffer
and DataView
not only reduces the cognitive strain required to remember the subtle differences between both APIs, it also allows your code to run, unchanged, on multiple enviromnents.
Working with ArrayBuffer in Node.js
One thing to notice though, some methods of the file system API in Node.js will give you a Buffer
. Thankfully Buffer
is now a subclass of ArrayBuffer
:
import { readFile } from 'node:fs/promises'
const buf = await readFile('meme.avif')
const arrayBuffer = buf.buffer
Other things you can do with an ArrayBuffer
In addition to DataView
, you can use a typed array to read or modify an ArrayBuffer
:
const arrayBuffer = new ArrayBuffer(8)
const typedArray = new Uint8Array(arrayBuffer)
typedArray[0] = 64
typedArray[1] = 65
The different typed arrays come with all the usual array methods (filter
, map
, reduce
…).
You can also create a Blob
from an ArrayBuffer
to represent a binary file for example:
const blob = new Blob([arrayBuffer], { type: 'image/avif' })
postToTheFediverse(staus, { media: [blob] })
Node’s APIs getting closer to the browser
The availability of APIs like ArrayBuffer
and DataView
in Node.js is another step towards bridging the gap between the different JavaScript runtimes and reducing fragmentation. This is, for me, one of the most exciting develoment that recently happened to Node.js, together with the support for ESM!
